Model No. :
PACK G2 5.0Warranty :
10 YearsNominal Battery Energy :
5kWhNominal Voltage :
51.2VBattery Capacity :
100AHDimension(mm) :
600*480*189Weight(kg) :
100Calendar Life :
6000 timesCertification & Safety Standard :
CE/UN38.3
Compatible Inverters List

Specification of PACK G2-5.0
| Model | PACK G2-5.0 |
| Battery Module Type | LiFePO4 |
| Nominal Voltage (V) | 51.2 |
| Nominal Capacity (KWH) | 5.12 |
| Usable Energy (KWH) | 4.096 |
| Operatin Voltage (V)) | 40~58.4 |
| Recommended Charge & Discharge C Rate | 0.5C |
|
Recommend Charge/
Discharge Current (A)
|
50 |
|
Max Charge/
Discharge Current(A)
|
100 |
| Dimensions (W*D*H) | 600*480*189 |
| Net Weight (kg) |
55 |
| Communication | RS485/RS232/CAN |
| Working Temperature |
0℃~50℃ Charge - 10℃~50℃ Discharge
|
| Shelf Temperature |
-20℃~60℃
|
| Protection Level | IP65 |
| Expansion | Up to 15 units in parallel |
| Certification | CE/IEC/UL/UN38.3/MSDS |
| Design Life | 10 years+ |
| Cycle Life | >6000 |
| Warranty | 10 years |

Application Scenarios
