● Up to 27A PV input current perfect for high power modules
● Outputs high quality pure sine wave AC power
● 4-6kW load power to meet the needs of most households
● Can work without battery mode
● Industrial design with a modern aesthetic look
● Easy to install and simple to use
● Up to 6pcs in parallel
● Both single phase and three phase parallel options
● Solar Charger Controller up to 200A charging current
● Support for Li-ion battery BMS communication
● Exclusive Li-ion battery BMS dual activation
● Time-slot function to save cost with peak-valley tariff
Model No. :
HITTO HM seriesWarranty :
2 YearsMax. Power :
4000W / 6000WOutput Voltage :
230V Single Phase 60HzBattery Voltage :
48VdcInput Voltage :
60-450VdcDimension(mm) :
434*311*126.5mmWeight(kg) :
8.5kgDisplay :
LCDCertification & Safety Standard :
CE

Datasheet
|
Models |
4000W |
6000W |
|
AC mode |
|
|
|
Rated input voltage |
220/230Vac 50/60Hz |
220/230Vac 50/60Hz |
|
Frequency |
50Hz/ 60Hz (Auto detection) |
50Hz/ 60Hz (Auto detection) |
|
Inverter mode |
|
|
|
Output voltage waveform |
Pure sine wave |
Pure sine wave |
|
Rated output power (VA) |
4000 |
6000 |
|
Rated output power (W) |
4000 |
6000 |
|
Power factor |
1 |
1 |
|
Rated output voltage (Vac) |
230Vac |
230Vac |
|
Bypass breaker specifications |
120A |
150A |
|
Rated battery input voltage |
24V |
48V |
|
AC charging |
|
|
|
Battery type |
Lead acid or lithium battery |
Lead acid or lithium battery |
|
Maximum charge current |
100A |
100A |
|
Charge voltage range |
24Vdc |
48Vdc |
|
PV charging |
|
|
|
Maximum PV open circuit voltage |
500Vdc |
500Vdc |
|
PV operating voltage range |
60-450Vdc |
60-450Vdc |
|
Maximum output power |
4000W |
6000W |
|
PV charging current range (can be set) |
120A |
120A |
|
Communication interface |
|
|
|
Communication interface |
USB/RS485(WiFi/GPRS)/Dry node control |
|
|
Humidity range |
<60dB |
|
Product Overview

Parallel Diagram

Without Battery Working Mode
